Description
Ice Type & Size
Product spec.
- Heat rejection (at 32°C/wt 21°C): 2870W (2470 kcal/h)
- Ice production per 24 hours (15mm): 225kg (at 10°C/wt 10°C) / 215kg (at 21°C/wt 15°C) / 195kg (at 32°C/wt 21°C)
- Water consumption per 24 hours (at 21°C/wt 15°C): 0.40 metre cube / 1.9 Litres/1kg ice
- Ice production (at 21°C/wt 15°C): 17 min (freeze cycle time) / 2.83kg/140pcs (per cycle)
- Ice bin model: B-301SA
Operating conditions
- Voltage range: 198V-254V
- Ambient temperature: 1-40°C
- Water Supply: 5°-35°C / 0.07-0.8 Mpa / 7.25-116 PSI
- AC Supply Voltage: 1/220-240V / 50 Hz
