Description

Ice Type & Size

Product spec.

• Heat rejection (at 32°C/wt 21°C): 1460W (1256 kcal/h)
• Ice production per 24 hours (15mm): 138kg (at 10°C/wt 10°C) / 120kg (at 21°C/wt 15°C) / 98kg (at 32°C/wt 21°C)
• Water consumption per 24 hours (at 21°C/wt 15°C): 0.18 metre cube
• Ice production (at 21°C/wt 15°C): 23 min (freeze cycle time) / 2.1kg/238pcs (per cycle)
• Storage capacity: 55kg
• Self-contained ice bin

Operating conditions

• Voltage range: 198V-254V
• Ambient temperature: 1-40°C
• Water Supply: 5°-35°C / 0.07-0.8 Mpa / 7.25-116 PSI
• AC Supply Voltage: 1/220-240V / 50 Hz
